Eaton Bussmann series FNQ fuse, Time-delay, Motor control transformers, Circuits with in-rush currents, 0.125 A, Non-indicating, Ferrule end x ferrule end, 10 kAIC at 500 Vac, Nickel-plated bronze endcap, Standard, 500 V.
Standards
| Product Attribute | Attribute Value |
|---|---|
| Eaton | |
| Product Category: | Industrial & Electrical Fuses |
| RoHS: | N |
| FNQ | |
| Midget Fuses | |
| 125 mA | |
| 500 VAC | |
| Time Delay / Slow Blow | |
| 10 kA | |
| Cartridge Fuses | |
| Holder | |
| Clip | |
| 5AG Midget (10.3 mm x 38.1 mm) | |
| Bulk | |
| Brand: | Bussmann / Eaton |
| Diameter: | 10.3 mm |
| Length: | 38.1 mm |
| Product Type: | Industrial Power Fuses |
| 10 | |
| Subcategory: | Fuses |
| Type: | Time Delay Fuse |
| Part # Aliases: | FNQ-1-8 |
| Unit Weight: | 0.400000 oz |
Â
GENERAL SPECIFICATIONS
- PRODUCT NAME: Eaton Bussmann series FNQ fuse
- CATALOG NUMBER: FNQ-1/8
- MANUFACTURER: Cooper Bussmann
- CATEGORY: Fuse
- ITEM SUBCATEGORY: Low Voltage Fuse
- FAMILY: CC-Tron
- UPC: 051712786171
- GTIN: 00051712786171
- EAN: 5027590449922
- PRODUCT LENGTH/DEPTH: 0.41 in
- PRODUCT HEIGHT: 1.5 in
- PRODUCT WIDTH: 0.41 in
- PRODUCT WEIGHT: 0.175 lb
- WARRANTY: Not Applicable
- COMPLIANCES: CE Marked
ELECTRIAL RATING
- AMPERAGE RATIONG: 0.125 A
- INTERRUPT RATING: 10 kAIC at 500 Vac
- VOLTAGE RATING: 500 V
PHYSICAL DETAILS
- MATERIAL: Nickel-plated bronze endcap
- PACKAGING TYPE: Standard
GENERAL INFORMATION
- CONNECTION: Ferrule end x ferrule end
- FUSE INDICATO: Non-indicating
- TYPE: FNQ
- SPECIAL FEATUERS: Non-indicating
PCN
Environmental Documents
Catalogs
Technical data sheets
Export product specification
Eaton Bussmann FNQ-1/8 Low Voltage Fuse
Click On The Image To Enlarge
Eaton Bussmann FNQ-1/8 Low Voltage Fuse
The Eaton Bussmann series FNQ fuse is a delay fuse designed specifically for motor control transformers and circuits with surge currents. It has excellent overload protection capability, which can withstand instantaneous high current impact and quickly cut off the circuit in case of short circuit or overload, ensuring equipment safety.
Product Features
- Delay Characteristics: The FNQ fuse adopts a dual element design, which can withstand the impact current generated when the motor starts or the transformer is energized, avoiding false melting.
- High breaking capacity: This fuse has a breaking capacity of 10kA at 500V AC voltage, which can effectively protect the circuit from damage caused by short-circuit current.
- Nickel plated bronze end caps: The two ends of the fuse are made of nickel plated bronze material, which has good conductivity and corrosion resistance, ensuring the stability and reliability of the connection.
- Non indicative design: FNQ fuses are non indicative, with a simple appearance, suitable for circuit systems that require compact design.
- Standard Certification: Complies with international standards such as UL, CSA, CE, etc., ensuring product quality and safet.
Application Scenarios
FNQ fuses are widely used in motor control, transformer protection, and circuits that need to withstand high surge currents. It is particularly suitable for the following scenarios:
- Motor Control: Protects the surge current during motor start-up to prevent accidental melting.
- Transformer circuit: Provides protection for small control transformers to ensure the safety of equipment in the event of overload or short circuit.
- Industrial Control Circuit: In industrial automation and control systems, it protects circuits from damage caused by short circuits and overloads.
Technical Specifications
- Rated current: 0.125 A.
- Rated voltage: 500V AC.
- Breaking capacity: 10kA RMS symmetry.
- Size: cylindrical, diameter 13/32 inches, length 1-1/2 inches.
- Material: Fiber tube shell, nickel plated bronze end cap.
Summary
The Eaton Bussmann series FNQ fuses are an ideal choice for motor control and transformer protection due to their excellent delay characteristics and high breaking capacity. It can not only withstand high surge currents, but also quickly cut off the circuit in case of short circuit or overload, ensuring the safe operation of the equipment.
