Bussmann TPL-BA Power Distribution Fuse

Bussmann TPL-BA Power Distribution Fuse

Engineered for Robust Circuit Protection in Demanding Environments

Overview

The Bussmann TPL-BA Power Distribution Fuse delivers ultra-high-performance overcurrent protection for critical power distribution systems. Designed for industrial, commercial, and utility applications, this cartridge-style fuse ensures reliable safeguarding against short circuits and overloads in circuits up to 600V AC/DC. Its robust construction and time-delay characteristics make it ideal for protecting transformers, feeders, bus ducts, and other high-load infrastructure.

Key Features

• High Interrupting Rating: 200 kA at 600V AC/DC, ensuring superior fault protection even in high-energy environments.
• Time-Delay Design: Withstands temporary inrush currents (e.g., motor startups) without nuisance tripping while responding rapidly to sustained overloads.
• Voltage & Current Range: Compatible with 600V AC/DC systems; ampere ratings span 30A to 600A.
• Blade Terminal Design: Features low-resistance BA-style blades for secure connections, minimizing heat buildup and voltage drop.
• Durable Construction: Compact cylindrical body built with heat-resistant materials for longevity in harsh conditions.
• Compliance: UL 248-10 and CSA C22.2 No. 248.10 certified; compatible with TPL fuse blocks for easy integration.

Applications

• Industrial switchgear, panelboards, and motor control centers (MCCs)
• Renewable energy systems (solar/wind farms)
• Data center power distribution units (PDUs)
• Heavy machinery, transformers, and busway protection
• Critical infrastructure (hospitals, airports, utilities)

Benefits

✅ Enhanced Safety: Prevents equipment damage and fire hazards by isolating faults within milliseconds.
✅ Optimized Performance: Low power loss design improves system efficiency.
✅ Easy Maintenance: Visual indication (optional) for quick fault identification; drop-in replacement minimizes downtime.
✅ Future-Proof: Interchangeable with legacy TPL-series fuses, simplifying upgrades.

Specifications

Trusted globally by engineers, the Bussmann TPL-BA fuse combines cutting-edge protection with rugged reliability—ensuring uninterrupted power and peace of mind in mission-critical systems.
